CAD/CAM/CAE Solutions
2D to 3D Conversion
It’s apparently important for companies to get their 2D data converted to 3D models to Converting 2D Drawings to 3D Models to empower design engineering.
In the field of modern industrial design 3D modeling is growing popularity among designers due to inherent advantages compared to 2d, it is more visual and proves to be easier to edit or modify.
We are helping companies to quickly convert the old 2D drawings to 3D model by our unique methodology with best practices with right expertise.
FaithPLM team has vast experience in 2D to 3D conversion with required precision and accuracy.
CAD Solutions
CAD customization is a process of achieving certain set of design task automation for improving productivity and quality with eliminating unwanted errors for enabling more time to designer to focus on addressing real challenges in the design domain and reduce lead time.
Today, many companies are looking for CAD customization to achieve the above facts. FaithPLM team is expertise in building solutions through customization which help customer to capture the knowledge base generated over the period and reuse it for automating various design and drawing related task.
FaithPLM team blends the knowledge of CAD technology and software development to address various requirement while automating design task/processes in s/w like SolidEdge, NX, CATIA & Pro-E using respective kernel and API offered along with C, C++, JAVA, .NET & Visual Basics.
Why CAD Customization for Design Automation from FaithPLM?
- In-depth knowledge of Design Engineering
- Proven software development methodologies </p>
- End to end solutions to address business requirement
CAE Analysis
CAE analysis is a process of applying CAE tools to analyze CAD geometry, allowing product designers to simulate and study the expected behavior of the product in different environments. Analysis helps the design to be refined and optimized to ensure that the finished product will have the high performance, high reliability, low weight, and low cost.
CAE Solutions:
- Mesh Generation: End to end solutions in preprocessing includes mesh generation for simple to complex components, batch meshing, mesh refinement based on required on analysis.
- Static Analysis: Linear and Nonlinear (Material and Contact nonlinearity), large deformation analysis to estimate stress, strain, deflection under the influence of various loading condition and factor and margin of safety.Critical stress paths identification and linearization to evaluate sectional stressalong with fatigue life evaluation and buckling load factor calculation.
- Dynamic Analysis: Transient, Frequency Response, Multi-body Dynamics and Fatigue Analysis to estimate natural frequencies, dynamic response under the influence of time varying, harmonic, shock and probabilistic loading conditions.
- Design Optimization: Identification of critical areas, material and size to avoid failure based on design constraint to enable design optimization.
- Product Simulation: Virtual Manufacturing Engineering, Aesthetics, Virtual build, Virtual audit, Ergonomics, Reachability and Serviceability in all respect.
Why CAE Solutions from FaithPLM Solutions?
FaithPLM Solutions has proven capabilities ofperforming various types of CAE analysis and analyzing results for achieving business goal of design optimization ranging from simple to complex components.
Unique Capabilities of FaithPLM Solutions includes:
- Expertise on Finite Element Analysis Procedures and Methods
- Proven capabilities in field failure analysis and elimination
- Expertise on SIMULATION data, knowledge & process management on Teamcenter Unified Platform
